Studies suggest Porphyromonas gingivalis (Pg) increased the incidence of oral squamous cell carcinoma (OSCC). However, fimA genotypes distribution of Pg, the origination of Pg in tissue, and its prognostic value are inconclusive. We aimed to investigate the frequency of fimA genotypes in OSCC patients, study the association between Pg and OSCC, and explore the prognostic value of Pg.
The abundance of Pg in saliva from the OSCC group and the OSCC-free group was analysed by qPCR. The presence of Pg was explored in OSCC tissue and para-cancerous tissue by in situ hybridization. The frequency of fimA genotypes in saliva and OSCC tissue was determined by PCR, then PCR products were sequenced and compared. Clinical data were extracted, and patients followed up for a median period of 23 months. Clinicopathological variables were compared with the abundance of Pg using Pearson Chi-square test or Fisher’s exact test. The disease-free survival (DFS) rate was calculated by Kaplan–Meier method with log-rank tests.
Comparing the OSCC-free group, 95 patients with OSCC showed a high abundance of Pg in saliva (P = 0.033), and OSCC tissue showed strong in situ expression of Pg compared with paired normal tissue. Patients with OSCC showed a dominant distribution of Pg with genotype I + Ib (21.1%), II (31.6%), and IV (21.1%). FimA genotypes detected in saliva were in accordance with those in OSCC tissue, there was, moreover, a significant similarity in amplified Pg fragments. Of the 94 responsive OSCC patients, the recurrence rate was 26.6% (25/94). Overabundance of Pg in saliva showed advanced pathologic staging (P = 0.008), longer disease-free time (P = 0.029) and lower recurrence rate (P = 0.033). The overabundance of Pg in saliva was associated with improved disease-free survival (P = 0.049).
This study indicated that Pg might involve in the pathogenesis of OSCC, Pg carrying fimA I, Ib, II, and IV were prevalent genotypes in patients with OSCC, the provenance of Pg in OSCC tissue might be from the salivary microbial reservoir, and the abundance of Pg in saliva might consider as a favorable potential prognostic indicator in OSCC.
There were approximately 354,864 new cases of lip and oral cavity cancer and 177,384 related deaths worldwide in 2018 . Oral squamous cell carcinoma (OSCC) is the most common malignant disease in the head and neck besides non-melanoma skin cancer. Traditionally, risk factors associated with OSCC included tobacco/alcohol consumption, betel quid chewing, virus infection, dietary factor, vitamin/mineral deficiencies, occupational exposures, and heritable conditions. However, accumulating epidemiologic, clinicopathologic, and molecular studies have proven that oral microbial species played an important role in the carcinogenesis of OSCC .
Porphyromonas gingivalis (Pg), an anaerobic Gram-negative bacterium, was associated with a high risk of OSCC in extensive studies [3,4,5,6,7,8,9]. However, the effect of Pg infection on the prognosis of OSCC is unclear. Recently, Pg infection in OSCC tissue showed a trend (HR 0.34; P = 0.055 in multivariate regression analyses) towards improved overall survival . Given that salivary microbiota is stable and saliva is easy and non-invasive to collect, saliva is an acceptable biofluid for the evaluation of the oral microbiome [11, 12]. We hypothesized that the abundance of Pg in saliva was associated with a favorable prognosis in patients with OSCC.
Fimbriae are crucial to initial attachment, organization of biofilms, and adhesion that mediate invasion and colonization of cells, although Pg has an arsenal of virulence factors, such as gingipain, lipopolysaccharide, and capsule . The major fimbriae fimA and the minor one mfa1 were two distinct fimbriae expressed in Pg. Six genotypes (types I-V, Ib) of fimA have been identified based on sequence variations. Previous studies have reported a high prevalence of fimA genotype II in periodontitis patients, and fimA genotype Ib, II and, IV are more aggressive [14,15,16,17]. However, no study was found evaluating the frequency of fimA genotypes in patients with OSCC.
In this study, we explored the association between Pg and OSCC. Meanwhile, we investigated the prevalence of fimA genotypes in patients with OSCC. To verify the origination of Pg in the OSCC tissue, we compared the frequency of fimA genotypes in saliva and those in OSCC tissues. Furthermore, we compared the amplified Pg fragments from OSCC tissue and those from saliva. The potential prognostic value of Pg in OSCC was also assessed.
Approval from the institutional review board was obtained at the Hospital of Stomatology Wuhan University before starting the study (2016–60). Informed consent was obtained from each patient.
The inclusion criterion was patients with primary OSCC managed by curative-intent, and a total number of 111 consecutive patients were included from October 2018 and April 2019. The exclusion criteria were patients: (1) received oral prophylaxis in the latest three months (one patient), (2) underwent radiotherapy and/or chemotherapy before surgery (three patients), (3) edentulous (two patients), (4) refused to receive surgery, (5) disagreed to participate in this study (four patients disagreed to the collection of saliva and six patients did not fast overnight before saliva sample collection).
A total number of 95 patients with OSCC (65 male and 30 female subjects, aged 21–82 years, mean age 55.8) treated in the hospital were included in this study. Pathological staging was stratified in accordance with the eighth edition of the American Joint Committee on Cancer . Except for one patient with bone metastatic OSCC, all patients were M0 category. The control group comprised 39 OSCC-free subjects (21 males and 18 females, aged 33–76 years, mean age 52.6) diagnosed with salivary gland disease, lymphadenopathy, lymphoma, buccal or tongue chronic infection, epulis, ranula, lipoma, lymphoepithelial cyst, and sebaceous gland carcinoma.
Clinical records were retrieved. Assessed clinicopathological variables included age, gender, systematic disease, location of the tumor, size, pathological report, smoking, alcohol consumption, and treatment. Systemic disease included hypertension, diabetes, coronary artery disease, and chronic hepatitis B. Sixty-four patients underwent surgery, twenty-two patients underwent surgery + radiotherapy (IMRT: 76 Grays to 63 Grays) and eight patients underwent surgery + chemo-radiotherapy (Docetaxel, Cisplatin, 5-Fluorouracil). Pathological diagnosis was established by one pathologist and confirmed by another experienced pathologist from the department of pathological at the Hospital of Stomatology Wuhan University.
Patients were followed up from discharge by telephone or clinical assessment. Pathologic confirmation of recurrence was obtained in patients with clinical signs or symptoms. Disease-free survival (DFS) is defined as the time (in months) from the date of discharge to March 2021 or until the date recurrence was diagnosed.
A total of 134 saliva samples were collected between 6 a.m. and 8 a.m. following an overnight fast and refrainment of tooth brushing. Subjects were asked to swish vigorously with 40 mL sterilized double distilled water (bacteria negative in PCR assay) for 1 min, and then to expectorate into another specimen tube . The saliva samples were centrifuged at 14,000 rpm for 15 min, and then the cell pellet was suspended in 1 mL of sterile TE buffer. Saliva samples stored at -80 ºC until testing.
Bacterial DNA was extracted from saliva samples using a commercial DNA extraction kit (DP302, Tiangen, China) according to the manufacturer’s protocol, except adding an enzymatic lysis step with lysozyme (20 mg/ml, 37 ºC, 60 min). The resultant DNA was stored at − 20 ºC until in PCR.
A total of 15 out of 95 fresh-frozen OSCC tissue samples were obtained. DNA was extracted using the Total DNA/RNA/Protein Kit (R6734, Omega Bio-tek, USA) according to the procedure recommended by the manufacturer. Quantification of Pg in saliva samples and detection of fimA genotypes were measured by Real-time quantitative PCR. Amplifications were performed in duplicate on Bio-Rad CFX96 thermal cycler (Bio-Rad Laboratories, USA). The primers, synthesized by Sangon Biotech (Shanghai, China), were listed in Table 1.
The reaction mixture of 20 μL was composed of 50 ng saliva DNA template or 2 μL tissue DNA template, 0.4 μM of the specific primers, ChamQTM SYBR® qPCR Master with a final concentration of 1X (Q311, Vazyme, China), and an appropriate dose of sterilized DNase-RNase-free water. The conditions for Real-time quantitative PCR were as follows: 94 ºC for 5 min, then 28 cycles for Pg or 40 cycles for fimA genotypes of 30 s at 94 ºC, 45 s at 58 ºC or 60 ºC, and 1 min at 72 ºC; with a final extension of 10 min at 72 ºC. Melting curves were generated from 60 ºC to 95 ºC and read every 0.5 ºC for 5 s. An average Ct value was obtained. The ΔCt for Pg was determined by subtracting the Ct value of Pg from that of universal primer. The relative abundance of Pg was calculated by the 2−ΔΔCt method.
Amplified PCR products of fimA genotype from Real-time quantitative PCR were checked on 2% agarose gel (ST004L, Beyotime, China). This was done using 1X Tris Acetate-EDTA buffer (TAE) from 50X TAE (ST716, Beyotime, China). Gels were stained with 4S GelRed (A616697, Sangon Biotech, China). Image results were captured with the digital imaging system (NuGenius, SYNGENE, UK). One pair of amplified Pg fragments from OSCC tissue and saliva were confirmed following nucleotide sequencing by Sangon Biotech (Shanghai, China) and the correlation of two sequences by aligning two sequences with BLAST (http://www.ncbi.nlm.nih.gov/BLAST) .
Among 15 OSCC tissue patients, remaining OSCC tissue and normal tissue adjacent to OSCC from one patient were fixed in 4% paraformaldehyde, paraffin-embedded, and cut into 4 μm sections, which was stained with haematoxylin and eosin, gram and subjected to in situ hybridization (ISH) using Enhanced Sensitive ISH Detection kit I (POD) (MK1030, Boster, China) according to the manufacturer's instructions. The probe is listed in Table 1. Omission of the probe was obtained as the negative controls.
Shapiro–Wilk test was used to assess whether or not data were normally distributed. Normally distributed data were analysed by Student’s t test and presented as Mean ± Standard Deviation. The data without normal distribution presented as the median and inter-quartile range (M, Q) and analysed by the Mann–Whitney U test. Categorical variables were analysed by Pearson Chi-square test or Fisher’s exact test. The cutoff point to convert the number of Pg 16S rRNA gene copies into categorical data (low, < 4 and high, ≥ 4) was performed using X-tile software . The Kaplan–Meier log-rank test was performed to compare the DFS. All two-tailed P values < 0.05 were considered significant. All analyses were carried out using IBM SPSS Statistics software (IBM SPSS Statistics V.25.0, USA).
As showed in Table 2, compared with controls matched for gender and age (P > 0.05, respectively), OSCC patients showed an overabundance of Pg in saliva (P < 0.05). To exclude contamination of samples, Pg was also detected in tissues by ISH from one patient. Compared with normal tissue which is adjacent to OSCC, OSCC tissue showed strong in situ expression of Pg (Fig. 1).
To evaluate the frequency of different fimA genotypes in patients with OSCC. Amplified PCR products of fimA genotype were checked on 2% agarose gel electrophoresis. The distribution of fimA genotype from the saliva of 95 OSCC patients was listed in Table 3. FimA genotype I and Ib were detected in 20 (21.1%) specimens, genotype II in 30 (31.6%) specimens, genotype III in 4 (4.2%) specimens, genotype IV in 20 (21.1%) specimens, genotype V in 2 (2.1%) specimens. We also found two or more genotypes of fimA from one sample. FimA genotype I, Ib, and II was detected in 1 (1.1%) participant, genotype I, Ib, and III in 2 (2.1%) participants, genotype I, Ib and IV in 1 (1.1%) participant, genotype I, Ib, and V in 1 (1.1%) participant, genotype II and IV in 3 (3.2%) participants, genotype I, Ib, II, and IV in 1 (1.1%) participant. Ten participants showed negative on 2% agarose gel electrophoresis assay. This finding supported the dominant distribution of Pg with genotype I, Ib, II, and IV in saliva from OSCC patients.
To clarify the homogeneity of Pg between saliva and OSCC tissue, the frequency of fimA genotypes was also detected in fifteen OSCC tissues. Among fifteen patients, the fimA genotypes detected in saliva were in accordance with those in OSCC tissue (Table 4). Besides, amplified Pg fragments from OSCC tissue and those from saliva were examined in one patient, we found a significant correlation in nucleotide similarity (Figs. 2, 3). Collectively, these results implied that Pg in OSCC tissue might originate from the salivary microbial reservoir.
The deadline for follow-up was March 2021. After a median follow-up period of 23 months (range 3 to 28 months). Ninety-four patients were available for the follow-up visit, but one patient was non-responsive to any form of contact. Recurrence was diagnosed as the endpoint for 25 patients, with a 26.6% (25/94) cumulative recurrence rate (Fig. 4).
Clinicopathological information of OSCC patients is shown in Table 3. The distribution of clinicopathological outcomes was compared with the abundance of Pg to assess the potential prognostic variables. Patients with the overabundance of Pg in saliva had an advanced pathologic staging than those with a low abundance of Pg (P = 0.008). While, compared with the weak group, patients with the overabundance of Pg in saliva had a longer disease-free time (Z = -2.188, P = 0.029). The overabundance of Pg in saliva was associated with a lower recurrence rate (P = 0.033). However, differences were not statistically significant by age, gender, systemic disease, smoking, alcoholic consumption, location, differentiation grade, and fimA genotypes. Neither single fimA genotype was statistically significantly associated with any clinicopathological parameters.
A total of 94 cases with follow-up data were included in the survival analysis. Univariate analysis showed that the overabundance of Pg was a favorable prognostic factor (Chi-square = 3.86, P < 0.05) (Fig. 5). Statistically, age, gender, FimA genotypes, systemic disease, pathologic staging, smoking, alcoholic consumption, location, differentiation grade, and treatment were not the independent prognostic indicators. Consequently, our results showed the overabundance of Pg was associated with favorable outcomes in patients with OSCC.
With recent breakthroughs in high-throughput genetic-based tools, there has been a hot issue concerning the relationship between the oral microbiome and neoplasms, especially OSCC. Recently accumulating evidence indicated the relationship between Pg and OSCC. Immortalized oral keratinocytes stimulated with Pg led to a more aggressive malignant profile phenotype and contributing to enhanced tumor features . The serum immunoglobulin G antibody against Pg was higher in OSCC patients compared with non-OSCC patients . Pg increased the size and the multiplicity of carcinoma to promote the development of oral cancer . Previous studies have confirmed the association between Pg and OSCC by examining the abundance of Pg in the saliva of patients and unveiled that patients with medium and poor differentiation, overall clinical stage III and stage IV, lymph node metastasis, and shorter overall survival associated with Pg involvement [3, 10]. But in multivariate analyses, colonization of Pg was a favorable prognostic factor, with a strong tendency towards statistical significance (HR 0.340, 95% CI 0.112–1.025, P = 0.055) . Our study also verified the overabundance of Pg from OSCC patients compared with OSCC-free subjects in saliva, and the overabundance of Pg in saliva was more likely to correspond with the advanced pathological stage. Those results are in resonance to previous reports . To exclude contamination of samples, we examined the presence of Pg in OSCC tissue by ISH. Consistent with the previous report , there was high enrichment of Pg in OSCC tissue compared with normal tissue adjacent to OSCC. After a median follow-up period of 23 months, the OSCC recurred in 26.6% (25/94) of patients. As the same as our findings, it was reported early-stage patients have a 90–95% survival rate for one year or more, and advanced-stage patients have a 65–70% survival rate .
In this study, compared with the weak group, patients with the overabundance of Pg in saliva had a longer disease-free time and lower recurrence rate. Those suggested that Pg may affect the prognosis of OSCC. Most interestingly, we found the overabundance of Pg is a favorable prognostic factor for DFS. Contrary to popular belief, they found that Pg was associated with a higher risk of pancreatic cancer [27, 28], esophageal squamous cell carcinoma [29, 30], and oral squamous cell carcinoma [3, 10]. Meanwhile, Pg was associated with poor overall survival rates in esophageal squamous cell carcinoma . Furthermore, patients with a high level of Pg had the worst prognosis in esophageal squamous cell carcinoma . Besides the population and follow-up period contributed to this prognostic incongruity, the inherent mechanistic also should be taken into consideration.
One of the most vital virulence in Pg has been supposed to the presence of fimbriae, which plays an important role in adhesion, colonization, and invasion to tissues . Most of the studies focused on the distribution of fimA genotypes in periodontitis. However, the frequency of fimA genotypes in OSCC was not clear. FimA genotypes I and Ib could be discriminated by Rsa I enzyme digestion. However, discrimination of genotypes I and Ib seems to be improbable . Besides, there were no differences in the immunological analysis between fimA I and Ib fimbriae . So we consider fimA genotypes I and Ib as a whole.
In this study, the association of fimA genotypes and clinicopathological parameters was not statistically significant. However, the predominantly detected fimA genotypes in OSCC were genotypes I, Ib, II, and IV. Several studies concluded that nucleotide genetic variation was likely associated with virulence. Some reported fimA genotypes Ib, II, and IV are the most virulent fimbriae in periodontitis and assist in adhesion and invasion [14, 33]. It was reported that fimA genotype Ib, II, and IV led to more severe infections and inflammations [34, 35]. Clinical isolation of Pg from chronic periodontitis patients also supported the virulence of fimA genotypes Ib, II, and IV . Different Pg fimA genotype was injected subcutaneously, and Nakano et al. found that the weakest inflammatory response was induced by genotype III . FimA genotype V was the least amount of genotypes in this study. The reason might be the low prevalence (0–29%) of this genotype . Single Pg fimA genotype was determined by more than 70% of OSCC patients, and two or more genotypes were also detected in a subset of the subjects. Approximately 10% of the samples were multiple genotypes in this population, which was less than the results of other studies [14, 17]. Researchers attributed to the limitations of PCR in the discrimination of fimA genotypes and the possibility of classifying new genotypes .
Due to the conservative properties of DNA, the bacterial 16S ribosomal DNA allows identification of the genus and species. Analysis of Pg nucleotide sequences in the OSCC tissue and those in the saliva showed a homology of 100%. Moreover, the distribution of fimA genotypes in OSCC tissue is according to those in saliva. Those results support the origination of Pg in OSCC tissues might be from the salivary microbial reservoir .
The limitations of this study included the short follow-up period and small sample. Further research will need to be done to elucidate the mechanism of the prognostic role. Except for fimbriae of Pg, important virulence included: encapsulation (K1–K6), gingipains (types A, B, C) as well as lysine-specific types I and II, may also involve in the carcinogenesis of OSCC. Those remain to be uncovered in future studies.
This study found the overabundance of Pg was associated with OSCC, and patients with advanced pathological stage, longer disease-free time, and the lower recurrence rate were related to the overabundance of Pg. Meanwhile, the overabundance of Pg was a favorable prognostic factor in patients with OSCC. Furthermore, there was a dominant distribution of Pg with genotype I, Ib, II, and IV from patients with OSCC, and the origination of Pg in the tumor might be from the salivary microbial reservoir.
